This electrically operated solenoid valve allows the water supply to be automatically opened or closed. Thanks to the ⅜” connection, the valve is easy to connect to various water systems and irrigation applications, including accessories with a Gardena-compatible connection.
The valve is normally closed. This means that the water flow is automatically shut off when there is no voltage present. As soon as the solenoid valve is energized, the water can flow freely.
The spool is cooled during use by the passing water. This makes the valve suitable for long-term operation without the risk of overheating.
This magnetic valve operates according to the indirect-controlled principle. Therefore, sufficient head pressure from the water supply is required for proper operation.
Applications
This electric water valve is suitable for various applications where the water supply needs to be controlled automatically, such as:
- Automatic irrigation systems
- Water treatment and dosing systems
- Water detection and security systems
- Industrial and technical installations
- Garden and greenhouse installations
Available in 24 V or 230 V
The valve is available as standard in a 24 V version and can be safely used in low-voltage installations. When voltage is applied to the coil, the valve opens and water can flow. In the event of a voltage drop, the valve automatically closes.
For connection to the mains, an appropriate 230 V to 24 V power adapter is optionally available. This is supplied with a connecting cable and connector for quick installation.
Assembly instructions
For reliable operation, we recommend that the following points be taken into account:
- Always check the indicated flow direction on the valve.
- Install the valve so that the electrical connection is not exposed to moisture or water.
- The connection terminals are not polarity-sensitive.
- The valve can be easily attached with two M3 screws.
Please note: When purchasing some products on our webshop, basic knowledge of electrical engineering is required.
