Heating cable MF-10
Heating cable MF-10
0 Review | Add review
Heating cable for tile adhesive. Thin, flexible and waterproof, 10 Watt/m, in lengths from 20 m.

Product number

VN200040

€ 81,50
excl. VAT
€ 98,62
incl. VAT
Quantity:
Order


Product description

Thin, flexible heating cable with a strong plastic outer jacket. This 230V heating cable is equipped with waterproof sleeves and on one side a flat connecting cable, which is only 4 mm thick. Applications: floor heating in bathroom, kitchen. Also suitable for plant beds, billiard tables and other special applications. Beware of overheating: maintain at least 5 cm loop distance between hot cable parts everywhere. The heat output is approximately 10 watts per meter of cable length. A temperature controller (thermostat) is always required for this type of cable. See below at Related Products.

Applications

Up to 18 Watt/m
This heating cable is loadable up to 18 Watts per meter, provided it can dissipate its heat properly. Reducing the length up to 50% of the original length is technically possible, taking into account the safety of the new insulation.

Specifications

  • Connection voltage: 230 V
  • Power: approx. 10 W/m
  • Diameter: 3...4 mm
  • Sleeves: < 6 mm Ø
  • Bend radius: > 35 mm
  • Cold end: approx. 2.5 m
  • Connection: 3x 1 mm²
  • Outer jacket: TPE
  • Inner insulation: teflon
  • Earth screen: copper
  • UV resistant: no
  • Safety class: IPX7
  • Waterproof sleeves: yes
  • Certification: CE, VDE

*Please note: when purchasing some products on our webshop, a basic knowledge of electrical engineering is required (for installation).
